NixOS offers two distinct approaches for managing containers: declarative container management and imperative container management. These methods differ primarily in how containers are defined, updated, and integrated with the host system.

Here’s a breakdown of each approach and their differences:

1. Imperative Container Management

• Method: This approach uses the nixos-container command-line utility.
• Creation and Management: Containers are created with nixos-container create <name> and can be started, stopped, updated, and destroyed using commands like nixos-container start <name>, nixos-container update <name>, and nixos-container destroy <name>.
• Configuration:
  • When created, an imperative container gets its root directory in /var/lib/nixos-containers/<name> and a configuration file in /etc/nixos-containers/<name>.conf.
  • Its initial system configuration is stored at /nix/var/nix/profiles/per-container/<name>/system.
  • Configuration changes can be made by editing /var/lib/nixos-containers/foo/etc/nixos/configuration.nix on the host and then running nixos-container update foo.
  • Alternatively, a new configuration can be specified directly on the command line, which will overwrite the container’s configuration.nix.
  • Configuration changes can also be made from within the container using nixos-rebuild switch (after nix-channel --update).
• Networking: Imperative containers by default get their own private IPv4 address in the range 10.233.0.0/16. They operate within their own network namespace and possess the CAP_NET_ADMIN capability, allowing them to configure network settings (like firewall rules) without affecting the host’s network. To enable outside network access, Network Address Translation (NAT) rules must be set up on the host.
• Login and Execution: You can log in as root using nixos-container root-login <name> (host root access required) or get a regular login prompt with nixos-container login <name>. Arbitrary commands can be executed inside the container using nixos-container run <name> -- <command>.

2. Declarative Container Management

• Method: Containers are defined directly within the host’s configuration.nix file.
• Creation and Management: When nixos-rebuild switch is run on the host, the container is built. If it’s already running, it’s updated in place without a reboot. Containers can be configured to start automatically by setting containers.<name>.autoStart = true. They are started and stopped via their corresponding systemd service, e.g., systemctl start container@<name>.
• Configuration: The container’s configuration is specified as a Nix expression directly within the host’s configuration.nix.
• Networking: By default, declarative containers share the network namespace of the host, allowing them to listen on (privileged) ports, but they cannot change the network configuration. They can be given their own private network by setting privateNetwork = true, along with hostAddress and localAddress.

Key Differences Summarized:

• Configuration Location:
  • Imperative: Managed by individual configuration files (/etc/nixos-containers/<name>.conf) and directories (/var/lib/nixos-containers/<name>) on the host.
  • Declarative: Defined directly within the host’s central configuration.nix file.
• Update Mechanism:
  • Imperative: Containers are configured and updated independently from the host system using nixos-container update or nixos-rebuild switch from within the container.
  • Declarative: Containers are upgraded along with the host system when nixos-rebuild is run.
• Network Isolation (Default):
  • Imperative: By default, imperative containers receive a private IPv4 address and have their own network namespace, allowing them to perform arbitrary network configurations.
  • Declarative: By default, declarative containers share the host’s network namespace, meaning they don’t have independent network configuration capabilities.

Important Note: NixOS containers are not perfectly isolated from the host system. A user with root access inside a container can affect the host, so it is advised not to grant container root access to untrusted users.
