🧠 Reinforcement Learning Takes the Wheel: A Smarter Approach to RF Neuromodulation

RL-Driven RF Neuromodulation

Neuromodulation—using techniques like radiofrequency (RF) energy to precisely tune brain activity—holds immense promise for treating neurological conditions. However, achieving effective and safe closed-loop RF neuromodulation often relies on laborious, hand-tuned schedules for parameters like beam angle and power¹.

What if an intelligent agent could learn the optimal settings on its own, ensuring maximum therapeutic effect while strictly adhering to safety limits?

Our work demonstrates that a Reinforcement Learning (RL) agent can discover superior, safety-aware, single-beam settings, outperforming traditional scheduled approaches²²²².

🚀 The RL-Driven Solution: DQN for Precision Tuning

We trained a Deep Q-Network (DQN) to manage four critical parameters simultaneously: power ($P$), frequency ($f$), phase ($\phi$), and angle ($\theta$)³³³³³³³.

The agent’s goal is to maximize a target-state proxy while keeping the patient safe. It achieves this by optimizing its reward function:

$$r_{t}=\alpha~I_{target}-\beta~SAR(P)-\gamma~slew$$

This reward formula encourages maximizing the measured intensity at the target ($\alpha~I_{target}$) while penalizing Specific Absorption Rate (SAR) ($\beta~SAR(P)$) to maintain safety⁴⁴⁴⁴. SAR is the crucial safety constraint, representing the rate at which RF energy is absorbed by the body⁵⁵⁵⁵.

📊 Results: Outperforming the Baseline

The RL agent demonstrated significant improvements over a traditional hand-tuned sweep schedule baseline⁶⁶⁶.

Improved Efficacy: Our DQN agent achieved a 25% improvement in evaluation return compared to the baseline⁷.
Optimal Performance: The agent reached a median episode return of 100⁸.
Better State Tracking: The decrease in state reconstruction error alongside increased return suggests the agent is more effective at tracking the target state⁹⁹. The agent successfully reduced state reconstruction error to 0.05 (Mean Squared Error)¹⁰.

The graph below visually compares the performance:

Fig. 2. Evaluation returns. The DQN agent shows a higher evaluation return than the hand-tuned baseline¹¹¹¹¹¹¹¹¹¹¹¹¹¹¹¹¹¹.

🎯 Safety and Stability

A key component of this research is ensuring the agent operates within safety constraints. The intrinsic penalty on SAR in the reward function is vital. An ablation study confirmed the model’s ability to handle the safety proxy, consistently achieving high returns¹²¹².

Furthermore, the training reward curve (Fig. 1) shows the DQN agent’s consistent and rapid learning, with the episode return steadily increasing over 5 episodes:

Episode	Approximate Episode Return
1.0	50
2.0	60
3.0	78
4.0	90
5.0	95+

The agent consistently learns to maximize its return while minimizing the SAR penalty, representing a safe and efficient control policy¹³¹³.

💡 Conclusion and Future Direction

Our results show that an RL-driven approach to RF neuromodulation can consistently outperform a scheduled baseline within the same safety proxy¹⁴¹⁴. This work validates the use of a compact DQN with factorized discrete heads for fine-tuning RF parameters¹⁵¹⁵¹⁵¹⁵.

While this study uses a toy-but-physics-inspired environment¹⁶, future work will focus on:

Richer phantoms¹⁷.
Integrating real scanner latencies¹⁸.
Addressing multi-beam coupling¹⁹.

This is an important step toward autonomous, safe, and effective closed-loop RF neuromodulation therapies.
